Breach PTQ136
Thermal Monocular

Built for the rigors of law enforcement, the FLIR Breach PTQ136 spots the heat of suspects and objects in total darkness. Featuring the new FLIR Boson core and seven color palettes, the FLIR Breach offers unmatched tactical awareness. It also records photos and video. Remarkably compact and lightweight, the monocular easily slips into a pocket. It can also be helmet mounted.

$2,829.00

-

In stock

Export Statement
It is the responsibility of the buyer to comply with export control laws and regulations of the United States Government and to obtain export licenses if required. Learn more

See Clearly in Complete Darkness

The FLIR Breach PTQ136 detects the heat of suspects and objects in total darkness and in light fog, dust, or smoke, and even through light foliage and thin walls. Featuring the new FLIR Boson core and a compact design, the FLIR Breach weighs only 7.4 ounces (210 grams). It can be concealed in a pocket or mounted to a helmet with its mini-rail feature, while adding minimal weight to officers’ heavy gear. Additional features include onboard recording and seven palettes for fast detection of suspects or evidence, day or night.

Exceptional Vision

The advanced image processing of the internal FLIR Boson thermal core and a bright high definition display create excellent image clarity and provide better detection and classification, day or night.

Convenient Hands-Free Operation

For hands-free operation, the Breach PTQ136 has multiple mini-rail mounting points designed to allow for a wide variety of head mounts, helmet mounts, and to install additional equipment.

Superior Tactical Value

Choose from multiple palettes to perfect viewing during varied situations. Enhance situational awareness with a digital compass/inclinometer.

Built-In Recording

Document your operations with on-board video recording and image capture. Internal storage provides up to 2.5 hours of recording or up to 1,000 photos.

Made and Warranted in the USA

The FLIR Breach PTQ136 is made and supported in the USA. It comes with FLIR’s 10-year detector warranty for greater peace of mind.

System Overview
MPN TAB176WN8Q14001
UPC 849815008364
Detector Type 320 × 256 VOx Microbolometer
Digital Zoom 1× – 4× continuous
Eye Relief 16 mm
Field of View [H x V] 24° × 19°
Image Processing FLIR Proprietary Digital Detail Enhancement™
Internal Memory Up to 1,000 images and 2.5 hours of video on internal memory
Package Includes Thermal Monocular, CR123A Battery, Lens Cloth, Hard Case
Size 139 × 70 × 49 mm (5.5 × 2.7 × 1.9 in)
Start up < 1.5 seconds
Weight 210 g (0.46 lbs)
Lens System 9.1 mm; F/1.04
Optical Magnification
Environmental
Operating Temperature Range -20°C to +50°C (-4°F to +122°F)
Storage Temperature Range -40°C to +60°C (-40°F to +140°F)
Power
Battery Life (Operating) Up to 90 minutes at 20°C
Battery type One CR123A 3V Lithium battery
Presentation
Display Quad-VGA (1280 × 960) FLCOS
Video Output Digital Video
Control Panel Buttons Configures Operational Settings: Unit On/ Off, Display Brightness Control, Image Palette Control, Digital Zoom Control, On-Screen Menu Navigation, NUC.
Refresh Rate 60 Hz
Sensor Specficiations
Diopter Adjustment Range -5 to +5 dpt
* Specifications are subject to change without notice.

Introduction

Video Palettes on the new FLIR Breach
