DesignateIR-V™

Made in the USA, the Designate IR-V laser is the smallest and lightest, dual beam, tactical rifle laser available today. Built from synthetic nylon, this laser is designed to withstand recoil and will perform in all weather conditions. The Designate IR-V’s set-it, forget-it zero allows the user to zero the visible laser once. Then, both laser sights are precisely co-witnessed for accuracy.

$1,999.00

-

Export Statement
It is the responsibility of the buyer to comply with export control laws and regulations of the United States Government and to obtain export licenses if required. Learn more

DesignateIR-V™ Three Beam Laser / Green Visible Laser / Infrared Laser / VCSEL IR Illuminator / All New ARISAKA Defense Ambidextrous Fire Button / Arisaka Aluminum Mounting Plate / CQB IR Diffuser Bikini Cover / MADE IN U.S.A

Made in the USA, the Designate IR-V laser is the smallest and lightest, three beam, tactical rifle laser available today. Built from synthetic nylon, this laser is designed to withstand recoil and will perform in all weather conditions. The Designate IR-V's set-it, forget-it zero allows the user to zero the visible laser once. Then, both laser sights are precisely co-witnessed for accuracy. The laser's small footprint lies below the weapons line of sight and allows the user to effortlessly switch to iron sights. The user controls have been carefully engineered for minimal drag, reliability, and ease of use. The newly added illuminator utilizes VCSEL technology providing illumination with exceptional distance and beam quality. Comparable products cost well over $3000.00. The Designate IR-V offers the end user options that they can afford. Simple user controls and a small footprint are just a few of the reasons to own one. Best of all, US Night Vision has introduced this new laser at an extremely competitive price point. The included CQB Filter diffuses the beam and provides perfect illumination for close up / indoor work where long range illumination is not needed.

The DesignateIR-V™ is available in back, FDE, olive drab green and is compatible with all Crane certified remote pressure pad systems (optional).

Specifications

  • Green Visible Laser/ Infrared Laser / VCSEL Illuminator w/ Diffuser Filter
  • Innovative Fire Button Placement
  • Green / Infrared / VCSEL Laser Operation
  • MIL-STD Crane Remote Switch Connector
  • Remote Pressure Switch (Optional)
  • Arisaka Defense 1913 Picatinny Rail Mount
  • Arisaka Defense Fire Control Button (Momentary/Constant)
  • Easy To Use Selector Switch Vis/Off/IR/IR & Illuminator
  • Intuitive “User Only” Activation Light
  • Windage / Elevation Adjustable
General
SKU DIRVBK
Dimensions (L) 3.5″ x (W) 2.8″ x (H) 1.1″
Weight (w/ Battery) 8.oz
Battery (1) CR123
Battery Life > 4 hours
Environmental Mil 810G
Warranty 2 years
Visible Laser
Laser Color Green
Output Power > 5.0 mW Class 3R
Beam Divergence .5 mrad
Wavelength 520 nm
Range > 50 m Daylight
IR Laser
IR Laser Infrared
Output Power > .7 mW Class 3R
Beam Divergence .5 mrad
Wavelength 850 nm
Range > 1000 m
VCSEL Illuminator
VCSEL Illuminator Infrared
Output Power > .130 mW Class 3R
Beam Divergence 3 Degree
Wavelength 850 nm
Range > 1000 m

Additional information

Weight 1 lbs
Dimensions 6 × 4 × 1 in
Color

Black, FDE, OD Green
