Armasight by FLIR MNVD
Night Vision Monoculars

The MNVD is a multi-purpose night vision monocular. It can be hand held, head mounted, helmet mounted, or weapon mounted. With a 40° or 51° field of view (FOV), it provides a large visual field without needing to move the monocular. The MNVD uses advanced multi-coated optics and is built to last with a compact composite housing. Operating from a single AA alkaline battery or CR123A battery, the MNVD can run up to 40 hours.

Starts at $1,795.00

Starts at $1,795.00

Starts at $1,795.00
SKU: Array Category:
Export Statement

It is the responsibility of the buyer to comply with export control laws and regulations of the United States Government and to obtain export licenses if required.Learn more >

Armasight by FLIR MNVD night vision monoculars Armasight by FLIR MNVD night vision monoculars Armasight by FLIR MNVD night vision monoculars Armasight by FLIR MNVD night vision monoculars Armasight by FLIR MNVD night vision monoculars Armasight by FLIR MNVD night vision monoculars Armasight by FLIR MNVD night vision monoculars Armasight by FLIR MNVD night vision monoculars attached to head harness Armasight by FLIR MNVD night vision monoculars attached to tactical helmet Armasight by FLIR MNVD night vision monoculars attached to tactical helmet Armasight by FLIR MNVD actual night vision view 40 degree vs 51 degree field-of-view comparison 40 degree vs 51 degree field-of-view comparison

Exceptional FOV Plus Infrared Illuminator

Matches a Gen 2+ or Gen 3 tube with advanced multi-coated optics to provide either a crisp and clear 40° or 51° field of view (FOV). The large visual field makes it easier to track moving objects without needing to move the monocular. A built-in IR illuminator and flood lens enhance night vision and allows for reading in the dark.

Manual Variable Gain Control

The MNVD is equipped with a manual variable gain control so that the image brightness level can be selected by user to adjust for ambient light level in his area of operations.

Perfect Balance of Size and Performance

  • The MNVD is built with a tough, ergonomic composite housing that is water and fog resistant.
  • Only a single AA battery or one CR123 battery provides up to 40 hours of operation.

Flexible Mounting Options and Configurations

  • For hands-free operation, the MNVD includes head and helmet mounting options. It can be used as a night vision system that enables mobility, driving, short-range surveillance, and low light reading.
  • Operated by a single gain control knob.
  • When mounted to a helmet, the MNVD features flip-up-turn-off and a flip-down-turn-on.

Package Includes

Packing Box, Soft Carrying Case, Battery, Lens Tissue, Quick Start Guide

Optional Accessories

  • Swing Arm #172
  • Swing Arm #37
  • Dual Bridge
  • Goggle Kit #2
  • Helmet Mount #4
  • Dovetail to Weaver Transfer Piece #21
  • QRM – Quick Release Picatinny Mount Adapter #26/#142
  • Extended Rail Adapter #85
  • Universal Camera Adapter #45
  • Camera Adapter #46
  • Demist Shield #34
  • Sacrificial Window #30
  • Shutter Eye-Guard #82
  • ARFS3 – Advanced Range Finding Stadia for 3x Afocal Lens
  • ARFS5 – Advanced Range Finding Stadia for 5x Afocal Lens
  • 3x Afocal Lens #22 (Nyx-14, Nyx-14-Pro, N-14, Nyx-7 Pro)
  • 5x Afocal Lens (Nyx-14, Nyx-14-Pro, N-14, Nyx-7 Pro)
  • IR850XLR Afocal Doubler
  • IR850-XLR Detachable LED Extra Long Range Infrared Illuminator w/Dovetail to Weaver Transfer Piece #21
  • Mil-Standard Hard Shipping/Storage Case #101

Specifications

Generation 2 Model Specfications
Model MNVD-40 2SD MNVD-40 2ID MNVD-40 2HD
MPN NSMNYX14M429DS1 NSMNYX14M429DI1 NSMNYX14M429DH1
UPC 849815009934 849815009606 849815009613
IIT Generation Gen 2+: “Standard Definition” Gen 2+: “Improved Definition” Gen 2+: “High-Definition”
Magnification 1x standard (3x, 5x optional)
Photocathode Type Multi-Alkali
Lens System F/1.3; 27 mm
Field of View 40°
Focus Range 0.25m to Infinity
Eye Relief 17 mm
Diopter Adjustment -6 to +2 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes (built-in with pivotal flood lens)
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA (1.5 V) or 123A (3 V)
Battery Life Up to 40 hours at 20°C
Operating Temperature -40°C to +50°C (-40°F to +122°F)
Storage Temperature -50°C to +50°C (-58°F to +122°F)
Overall Dimensions 115 x 48 x 73 mm (4.6 x 1,9 x 2.8 in)
Weight 0.34 kg (0.75 lbs)
Warranty 2 Years
* All data subject to change without notice.



Generation 2 Model Specfications (Continued)
Model MNVD-40 2QS MNVD-51 2HD
MPN NSMNYX14M4Q9DI1 NSMNYX14M529DH1
UPC 849815009620 849815009743
IIT Generation Gen 2+: “Quick Silver” White Phosphor Gen 2+: “High-Definition”
Magnification 1x standard (3x, 5x optional)
Photocathode Type Multi-Alkali
Lens System F/1.3; 27 mm F/1.26; 19 mm
Field of View 40° 51°
Focus Range 0.25m to Infinity
Eye Relief 17 mm
Diopter Adjustment -6 to +2 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes (built-in with pivotal flood lens)
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA (1.5 V) or 123A (3 V)
Battery Life Up to 40 hours at 20°C
Operating Temperature -40°C to +50°C (-40°F to +122°F)
Storage Temperature -50°C to +50°C (-58°F to +122°F)
Overall Dimensions 115 x 48 x 73 mm (4.6 x 1,9 x 2.8 in) 109 x 48 x 73 mm (4.1 x 1.9 x 2.8 in)
Weight 0.34 kg (0.75 lbs) 0.31 kg (0.7 lbs)
Warranty 2 Years
* All data subject to change without notice.



Generation 3 Model Specfications
Model MNVD-51 3A MNVD-51 3AG MNVD-51 3G
MPN NSMNYX14M539DA1 NSMNYX14M5P9DA1 NSMNYX14M5G9DA1
UPC 849815009699 849815009705 849815009712
IIT Generation Gen 3: “High-Performance” Gen 3: High-Performance Thin-Filmed Auto-Gated IIT Gen 3: “Ghost” White Phosphor
Magnification 1x standard (3x, 5x optional)
Photocathode Type GaAs
Lens System F/1.26; 19 mm
Field of View 51°
Focus Range 0.25m to Infinity
Eye Relief 17 mm
Diopter Adjustment -6 to +2 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes (built-in with pivotal flood lens)
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA (1.5 V) or 123A (3 V)
Battery Life Up to 40 hours at 20°C
Operating Temperature -40°C to +50°C (-40°F to +122°F)
Storage Temperature -50°C to +50°C (-58°F to +122°F)
Overall Dimensions 109 x 48 x 73 mm (4.1 x 1.9 x 2.8 in)
Weight 0.31 kg (0.7 lbs)
Warranty 2 Years
* All data subject to change without notice.



Generation Flag Model Specfications
Model MNVD-51 3F
MPN NSMNYX14M5F9DA1
UPC 849815009729
IIT Generation “FLAG” Filmless Auto-Gated IIT (Advertised by competition as Gen 4)
Magnification 1x standard (3x, 5x optional)
Photocathode Type GaAs
Lens System F/1.26; 19 mm
Field of View 51°
Focus Range 0.25m to Infinity
Eye Relief 17 mm
Diopter Adjustment -6 to +2 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes (built-in with pivotal flood lens)
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA (1.5 V) or 123A (3 V)
Battery Life Up to 40 hours at 20°C
Operating Temperature -40°C to +50°C (-40°F to +122°F)
Storage Temperature -50°C to +50°C (-58°F to +122°F)
Overall Dimensions 109 x 48 x 73 mm (4.1 x 1.9 x 2.8 in)
Weight 0.31 kg (0.7 lbs)
Warranty 2 Years
* All data subject to change without notice.
