Armasight by FLIR PVS-14 Night Vision Monoculars
New!
Armasight by FLIR PVS-14 Night Vision Monoculars
New!
Armasight PVS-14 night vision monocular Armasight PVS-14 night vision monocular Armasight PVS-14 night vision monocular side view Armasight PVS-14 night vision monocular head harness Armasight PVS-14 night vision monocular show mounted to helmet Armasight PVS-14 night vision monocular shown mounted on assault rifle Armasight PVS-14 night vision monocular shown mounted on helmet while soldier aims with hand gun Armasight PVS-14 night vision monocular shown mounted on helmet while soldier aims with hand gun Armasight PVS-14 night vision monocular shown next to hand gun Armasight PVS-14 night vision monocular shown on weapon mount Armasight PVS-14 night vision monocular shown mounted on assault rifle 40 degree versus 51 degree field-of-view comparison 40 degree versus 51 degree field-of-view comparison

Armasight by FLIR PVS-14
Night Vision Monoculars

PVS-14 is a single-tube night vision system with a standard 40° field of view (FOV) or wide 51° FOV for broad peripheral vision in near zero light conditions. A wider FOV increases situational awareness while requiring minimal head turning, thereby reducing fatigue. The PVS-14 is compatible with a host of accessories, allowing it to be handheld, mounted to a helmet, headgear, weapon, or camera.

Starts at $2,289.00

Starts at $2,289.00

Starts at $2,289.00
SKU: Array Category:
Export Statement

It is the responsibility of the buyer to comply with export control laws and regulations of the United States Government and to obtain export licenses if required.Learn more >

Armasight PVS-14 night vision monocular Armasight PVS-14 night vision monocular Armasight PVS-14 night vision monocular side view Armasight PVS-14 night vision monocular head harness Armasight PVS-14 night vision monocular show mounted to helmet Armasight PVS-14 night vision monocular shown mounted on assault rifle Armasight PVS-14 night vision monocular shown mounted on helmet while soldier aims with hand gun Armasight PVS-14 night vision monocular shown mounted on helmet while soldier aims with hand gun Armasight PVS-14 night vision monocular shown next to hand gun Armasight PVS-14 night vision monocular shown on weapon mount Armasight PVS-14 night vision monocular shown mounted on assault rifle 40 degree versus 51 degree field-of-view comparison 40 degree versus 51 degree field-of-view comparison

Remarkable Field of View

Operate in darkness with ease! The PVS-14 provides a standard 40° field of view (FOV) or an even wider 51° FOV that minimizes head turning and reduces fatigue.

Versatile Design

  • Use as a handheld monocular
  • Position as a left or right eye monocular, or keep fully stowed away
  • Mount to a helmet, headgear, weapon, or camera

Covert operation

  • Manual gain control
  • Ergonomic, simple, easy to operate controls
  • Built-in IR illuminator

Package Includes

  • Packing Box
  • Soft Carrying Case
  • 1x AA Batteries
  • Lens Tissue
  • Instruction Manual with Warranty Card
  • ARMASIGHT by FLIR Day Light Filter
  • Sacrificial Window
  • Demist Shields
  • Tethering Cord
  • Head Mount Assembly
  • Brow Pads

Optional Accessories

  • MICH Helmet Mount Assembly USA #107 (PVS-7, PVS-14)
  • PASGT Helmet Mount Assembly USA #108 (PVS-7, PVS-14)
  • Weapons Mount #109 (PVS14/6015)
  • Extended Rail Adapter #85
  • ARFS3 – Advanced Range Finding Stadia for 3x Afocal Lens
  • RFS5 – Advanced Range Finding Stadia for 5x Afocal Lens
  • 3x Afocal Magnifier Lens #99
  • 5x Afocal Magnifier Lens #100
  • 3x Afocal Lens #22 with Adapter #24/#25 (PVS-7, PVS-14)
  • 5x Afocal Lens with Adapter #24/#25 (PVS-7, PVS-14)
  • IR850XLR Afocal Doubler
  • XLR-IR850 Detachable LED Extra Long Range Infrared Illuminator
  • Mil-Standard Hard Shipping/Storage Case #101

Specifications

Generation 2 Model Specfications
Model PVS-14 2HD PVS-14-51 2HD
MPN NAMPVS140129DH1 NAMPVS14M529DH1
UPC 849815003932 849815009835
IIT Generation Gen 2HD (High Definition) MG Gen 2+ “High-Definition”
Resolution 55-72 lp/mm
Magnification 1x
Photocathode Type Multi-Alkali
Lens System F/1.26; 19mm
Field of View 40° 51°
Focus Range 0.25m to Infinity
Diopter Adjustment -6 to +2 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes Yes (built-in with flood lens)
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA battery
Battery Life Up to 50 hours
Environmental Rating Waterproof
Mil Standard Compliant
Operating Temperature -51°C to +49°C (-59°F to +120°F) -40°C to +50°C (-40°F to +122°F)
Storage Temperature -51°C to +85°C (-22°F to +185°F) -50°C to +50°C (-58°F to +122°F)
Dimensions (without eyecup and lens cap) 115 x 48 x 73 mm (4.6 x 1,9 x 2.8 in)
Weight 0.35 kg (0.77 lbs) 0.32 kg (0.7 lbs)
Warranty 2 Years
* All data subject to change without notice.



Generation 3 Model Specfications
Model PVS-14 3A PVS-14 3AG PVS-14 3G
MPN NAMPVS140139DA1 NAMPVS1401P9DA1 NAMPVS1401G9DA1
UPC 818470011293 818470011309 818470019701
IIT Generation Gen 3A (High Performance) MG Gen 3AG High-Performance Thin-Filmed Auto-Gated IIT Gen 3G (“Ghost” White Phosphor) MG
Resolution 64-72 lp/mm 47-57 lp/mm
Magnification 1x
Photocathode Type GaAs
Lens System F/1.26; 19mm
Field of View 40°
Focus Range 0.25m to Infinity
Diopter Adjustment -6 to +4 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes (built-in with flood lens)
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA battery
Battery Life Up to 50 hours
Environmental Rating Waterproof
Mil Standard Compliant
Operating Temperature -51°C to +49°C (-59°F to +120°F)
Storage Temperature -51°C to +85°C (-22°F to +185°F)
Overall Dimensions 158 x 51 x 60 mm (6.2 x 2,0 x 2.4 in)
Dimensions (without eyecup and lens cap) 114 x 51 x 57 mm (4.5 x 2,0 x 2.2 in)
Weight 0.35 kg (0.77 lbs)
Warranty 2 Years
* All data subject to change without notice.



Generation 3 Model Specfications (Continued)
Model PVS-14-51 3A PVS-14-51 3AG PVS-14-51 3G
MPN NAMPVS14M539DA1 NAMPVS14M5P9DA1 NAMPVS14M5G9DA1
UPC 849815009866 849815009873 849815009880
IIT Generation Gen 3 “High-Performance” Gen 3 “High-Performance” Thin-Filmed Auto-Gated IIT Gen 3 “Ghost” White Phosphor
Magnification 1x
Photocathode Type GaAs
Lens System F/1.26; 19mm
Field of View 51°
Focus Range 0.25m to Infinity
Diopter Adjustment -6 to +4 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA battery
Battery Life Up to 50 hours at 20°C
Environmental Rating Waterproof
Mil Standard Compliant
Operating Temperature -40°C to +50°C (-40°F to +122°F)
Storage Temperature -50°C to +50°C (-58°F to +122°F)
Overall Dimensions 158 x 51 x 60 mm (6.2 x 2,0 x 2.4 in)
Dimensions (without eyecup and lens cap) 114 x 51 x 57 mm (4.5 x 2,0 x 2.2 in)
Weight 0.32 kg (0.7 lbs)
Warranty 2 Years
* All data subject to change without notice.



Generation Flag Model Specfications
Model PVS-14 3F PVS-14-51 3F
MPN NAMPVS1401F9DA1 NAMPVS14M5F9DA1
UPC 818470019046 849815009897
IIT Generation 3F – Filmless Auto-Gated IIT MG “FLAG” Filmless Auto-Gated IIT (Advertised by competition as Gen 4)
Resolution 64-72 lp/mm
Magnification 1x
Photocathode Type Filmless GaAs GaAs
Lens System F/1.2; 26mm F/1.26; 19mm
Field of View 51°
Focus Range 0.25m to Infinity
Eye Relief 17 mm
Diopter Adjustment -6 to +4 dpt
Manual Gain Control Yes
Bright Light Cut-off Yes
Automatic Shut-off System Yes
Infrared Illuminator Yes
IR Indicator Yes (in FOV)
Low Battery Indicator Yes (in FOV)
Power Supply One AA battery
Battery Life Up to 50 hours at 20°C
Operating Temperature -40°C to +50°C (-40°F to +122°F)
Storage Temperature -50°C to +50°C (-58°F to +122°F)
Overall Dimensions 114 × 51 × 57 mm (4.5 × 2.0 × 2.2 in)
158 × 51 × 60 mm (6.2 × 2.0 × 2.4 in)
Weight 0.32 kg (0.7 lbs)
Warranty 2 Years
* All data subject to change without notice.
